Καταστροφέας χόρτων AS 63 2T ES

Categories

Modern Allmäher for slopes and difficult terrain

Mulch where others hit their limits. The AS 63 2T ES is equipped with the world’s only 2-stroke engine that meets the requirements stipulated by the EU Emissions Directive 97/68/EC. The AS 2-stroke engine maintains engine lubrication regardless of position, enabling mowing on inclines of 40 degrees and more without the risk of engine damage. In addition, the AS 2-stroke engine is factory-equipped with an EasyStart function; the CDI digital ignition system cuts the rpms required to start in half. The 2-stroke engine’s high torque provides full power in high, wet grass while a third crankshaft bearing and friction discs on the wing blade protect the engine in the event of striking an obstacle. Large inflatable tyres with field studs offer ideal propulsion at speeds up to 4.0 km/h.
The drive-reduction transmission with a gear ratio of 1:13.44 allows the AS 63 2T ES to brake autonomously when moving downhill. The machine will not speed up when moving downhill, no matter how steep the incline. When in drive the AS 63 2T ES has a permanently locked limited slip differential which increases traction and safety, particularly on slopes.
Work rates reaching 2,400 m² per hour are possible due to a high-performance 2-stroke engine with up to 6.7 hp, variable drive and a 61 cm cutting width. The AS 63 2T ES easily cuts grass up to 100 cm high.

Simple, convenient and safe operation

The AS 63 2T ES works with operating levers that activate the parking brake, the traction drive, the limited slip differential and the blade clutch. Absolute safety for slope mowing is achieved by an automatic parking brake and limited slip differential which remains permanently locked while the machine is in drive. When the drive lever is released, the parking brake automatically engages and the AS 63 2T ES stops, whether on a slope or level ground. For convenient operation the guide bar is equipped with a V-handlebar which can be adjusted laterally and for height without tools. “VibrationProtect” vibration damping reduces hand-arm vibration to a minimum.

Product advantages

Engine suitable for slopes

The world's only AS 2-stroke engine with EasyStart has position-independent lubrication, ensuring safe operation even on steep slopes.

Mow and mulch in one step

The cross-blade system of this Allmäher easily cuts and shreds high growth with an impressive cutting performance and excellent mulching result.

Automatic parking brake

When the drive lever is released the machine stops automatically, whether on a slope or level ground.

Self-braking traction drive

The drive-reduction transmission with a 1:13.44 gear ratio delivers optimal propulsion and brakes autonomously when moving downhill.

Special feature: automatic locking differential

Only when the drive wheel is spinning, the differential lock activates automatically. Otherwise, it is inactive and the machine is freely controllable.

High cutting capacity

1:1.6 engine-blade reduction for high cutting capacity in dense growth.

Engine protection

Separate engine and blade shaft protects engine.

Conical mower deck

Conical mower deck generates an airflow that uniformly whirls the cuttings in the mulching unit, delivering excellent cutting results.

Λεπτομέρειες προίόντος

product-image

Variator

Ο ρυθμιστής ταχύτητας επιτρέπει τη μεταβλητή ρύθμιση της ταχύτητας κίνησης.

product-image

Αποσβέση κραδασμών

Το "VibrationProtect" μειώνει τους κραδασμούς στα χέρια στο ελάχιστο.

product-image

Εύκολη μεταφορά

Ο AS 63 μπορεί να διπλωθεί εύκολα για συμπαγείς διαστάσεις μεταφοράς.

product-image

Θέση καθαρισμού και συντήρησης

Ο συμπαγής σχεδιασμός του AS 63 επιτρέπει εύκολο και βολικό καθαρισμό.

Προδιαγραφές

Πλάτος κοπής 61 cm
Μέγιστο ύψος χόρτων 100 cm
Κατασκευαστής κινητήρα AS-Motor
Μοντέλο κινητήρα AS 165 ES
Κυβικά εκατοστά 165 cm³
Μέγιστη ιππόδύναμη 4,4/6,0 kW (hp)
Ιπποδύναμη 4,0/5,4 kW (hp)
Ταχύτητα 3800 στροφές ανά λεπτό
Συμπλέκτης μαχαιριού
Πλαϊνή εναπόθεση / όπισθεν εναπόθεση /
Κλειστού τύπου κοπτικό στοιχείο
Μονή λεπίδα / μαχαίρι τύπου σταυρού / σφυρία τύπου Υ / /
Ύψος κοπής 50 - 100 mm
κίνηση, μηχανική/υδροστατική /
Αριθμός ταχυτήτων Vario
Μέγιστη ταχύτητα 4 km/h
Διαφορικό περιορισμένης ολίσθησης
Αυτόματο χειρόφρενο
Χωρητικότητα δοχείου 3 ltr
Διαστάσεις Μ/Π/Υ 191x70x99 cm
Βάρος 77 kg
Änderungen und Irrtümer vorbehalten. Aus Angaben und Abbildungen können keine Ansprüche abgeleitet werden.

Accessories

product-image

Συσκευή αποτροπής εντόμων

Η συσκευή αποτροπής εντόμων της AS-Motor είναι ένα καινοτόμο εξάρτημα κοπής που προστατεύει τους επικονιαστές και την μικρή άγρια ζωή. Επιστημονικά δοκιμασμένη για να αυξήσει τα ποσοστά διαφυγής εντόμων, εξασφαλίζει βιώσιμο κούρεμα ενώ διατηρεί την αποδοτικότητα. Σχεδιασμένο για ανθεκτικότητα, προσαρμοστικότητα και εύκολη ολοκλήρωση με επαγγελματικά μηχανήματα κοπής της AS-Motor.

» read on
product-image

Ωρομετρητής

Τεκμηρίωση ωρών εργασίας.

product-image

Κιτ ανακύκλωσης χόρτου AS 62, AS 63

Για ακόμη λεπτότερη κοπή και πιο ομοιόμορφα αποτελέσματα κοπής σε γκαζόν με χόρτο μέχρι 40 cm ύψος.

product-image

Διπλοί τροχοί

Προαιρετικοί διπλοί τροχοί για βελτιωμένη πρόσφυση σε κλίσεις με γρήγορο κλείδωμα.

product-image

Κλισιόμετρο

Βολική οθόνη κλίσης κλίσης.

product-image

Φιλτροχωάνη

Ένα φίλτρο σνόρκελ σε υψηλή θέση τροφοδοτεί τον κινητήρα με αέρα χωρίς σκόνη.

product-image

Δίχρονο Λάδι της AS "Titan 2T"

Λάδι δύο χρόνων υψηλής απόδοσης, για μια βέλτιστη οικολογική αναλογία μίξης. Συνιστάται για όλους τους κινητήρες δύο χρόνων της AS. Έχει δοκιμαστεί και εγκριθεί για την συνιστώμενη αναλογία μίξης 1:100. Είναι επίσης κατάλληλο για αναλογία μίξης 1:50. Αντικαθιστά το προηγούμενο λάδι μας TITAN 2T 100S, το οποίο δεν είναι πλέον διαθέσιμο.

product-image

Υγρό σφραγιστικό ελαστικών “Plattfuss-Stop”

Μειώνει τους χρόνους βλάβης λόγω σκασμένων ελαστικών (950ml)

» read on
