High-grass, ride-on mower with permanent all-wheel drive and more ground clearance

The AS 940 Sherpa 4WD XL enables comfortable and safe mowing on slopes. A rated power of 21.2 hp at 708 cm3 is produced by the professional 2-cylinder OHV engine from Loncin. Its permanent all-wheel drive, XL tyres with field stud tread, low centre of gravity and low total weight of only 302 kg provide stability on slopes. Hydrostatic transmission allows the precise adaptation of speed to match the terrain, reaching 6.7 km/h and 6.5 km/h in reverse. Just one lever controls the drive, brake and parking functions for easy operation, while limited slip differential can be activated for excellent propulsion and traction in extreme situations. A brake pedal returns the drive lever to neutral and automatically engages the parking brake.

The AS 940 Sherpa 4WD XL’s surfing mower deck is equipped with AS cross-blade technology in which bearing-supported blades cut the grass, while a mulching blade positioned above them shreds the cuttings. The mulched grass is then deposited between the wheels for added safety on slopes and wet grass, while the mower deck’s surfing suspension yields upwards to obstacles, protecting the blades and turf from damage. With a 90 cm cutting width, the AS Sherpa 940 4WD XL achieves work rates reaching 5,500 m² per hour. Cutting heights can be adjusted to 5 levels from 80–135 cm and an optional mulch kit is available for even finer mulching results.

Maximum comfort for long work days

The AS 940 Sherpa 4WD XL performs even under harsh conditions thanks to its highly stable tubular frame. A length-adjustable seat and seat spring package mean operators up to 2 meters tall can operate the machine comfortably while a low centre of gravity, folding bar and branch deflectors are added safety features. Integrated lashing points enable secure transport.

Designed for continuous operation

Two separate ventilation circuits for the engine and hydrostatic transmission prevent overheating: the engine takes in air from above and discharges it to the side, while the hydrostatic transmission takes air from the rear and discharges it downward. This system ensures a long service life.

The all-wheel drive ride-on mowers from AS Motor in a new design

The 2023 all-wheel drive models of the AS Motor 940 Sherpa family will appear in new splendour in the future. With new paintwork, an additional front panel and the newly designed decals, the Sherpa’s are even more attractive. But the 2023 model year of the AS 4WD Sherpa family also offers some technical innovations.

The new ATV tyres on the AS 940 Sherpa XL and the remote-controlled ride-on mower AS 940 Sherpa RC feature even better performance when driving across slopes and better climbing ability. In future, all AS Motor 4WD Sherpa models will be equipped with the AS tyre sealant Plattfuss-Stop as standard – downtimes due to flat tyres will be a thing of the past. The new fuel tank of the Sherpas offers more volume (17 litres), a larger tank opening, a fuel level indicator and a closed circuit with less fuel evaporation. The new locking mechanism of the foldable bar ensures easier handling and improved freedom of movement when operating the driving lever. In future, the protective cloth between the engine and the seat will no longer be elaborately riveted, but locked in place by robust magnets. Accessibility to the engine, for example when adjusting the valves or changing the oil, is significantly improved. This was an idea from AS-Motor users and dealers. Many thanks for this practical improvement idea.

Product advantages

All-wheel drive (AS 940)

Permanent all-wheel drive ensures better traction uphill and stronger, safer braking downhill.

Surfing mulch-mower deck

Closed mower deck with AS cross-blade system. The main blade cuts, the cross-blade chops the cuttings. The surfing mower deck gives way upward on uneven terrain to protect against damage.

Ergonomic sitting position provides excellent driving comfort

Length-adjustable driver seat, innovative seat suspension and ergonomic sitting position provide comfort for tall operators during long work periods.

Stable tube frame

High stability and torsional rigidity with heavy load.

Optimal all-terrain mobility

Field stud tyres, switchable limited slip differential and an engine suitable for slopes ensure powerful traction on difficult terrain.

Variable hydrostatic transmission (ride-on mower)

Easy adaptation of the speed to every terrain with integrated, mechanical parking brake in the drive lever.

Stable, folding bar

Greater operator safety in the machine's limit area.

Excellent – German Design Award Winner 2023

The consistently sustainable product design of the powerful high grass mowers convinced the top-class jury of the German Design Award. In the citation it says: “The AS Sherpa 4WD XL was developed specifically for mowing tall grass meadows, which its striking functional design expresses perfectly. A compact ride-on mower reduced to the essentials for sustainable and ecologically oriented green maintenance.”

Λεπτομέρειες προίόντος

product-image

Κοπτικό σύστημα AS mulching

Κλειστό κοπτικό σύστημα με σύστημα διασταυρούμενων λεπίδων και λεπίδες με ρουλέμαν που υποχωρούν σε εμπόδια.

product-image

Ξεχωριστή παροχή αέρα για ψύξη

Ξεχωριστή ψύξη αέρα για τον κινητήρα και τον υδροστατικό κιβωτισμό ταχυτήτων βελτιστοποιούν την απόδοση.

product-image

Διαφορικό περιορισμένης ολίσθησης με διακόπτη

Άνετη ενεργοποίηση του διαφορικού περιορισμένης ολίσθησης μέσω πεντάλ για εξαιρετική πρόωση και έλξη.

product-image

Λάστιχα XL

Λάστιχα XL για επιπλέον απόσταση από το έδαφος 30 mm.

Προδιαγραφές

Πλάτος κοπής 90 cm
Κατασκευαστής κινητήρα Loncin
Μοντέλο κινητήρα LC2P77F
4χρονος κινητήρας, Μονοκύλινδρος /Δικύλινδρος /
Κυβικά εκατοστά 708 cm³
Μέγιστη ιππόδύναμη 16,0/21,7 kW (hp)
Ιπποδύναμη 15,6/21,2 kW (hp)
Ταχύτητα 3400 στροφές ανά λεπτό
κἰνηση, 2WD όπισθεν / 4WD μόνιμη /
Κίνηση, υδροστατική μετάδοση κίνησης
Μέγιστη ταχύτητα 6,7 km/h
Διαφορικό περιορισμένης ολίσθησης
Αυτόματο χειρόφρενο
Μονή λεπίδα / μαχαίρι τύπου σταυρού / σφυρία τύπου Υ / /
Πλαϊνή εναπόθεση / όπισθεν εναπόθεση /
Κλειστού τύπου κοπτικό στοιχείο
Κοπτικό στοιχείο που επιπλέει
Ύψος κοπής 80 - 135 mm
Χωρητικότητα δοχείου 17 ltr
Ανάρτηση θέσης χειριστή, Εργοστασιακή /Προαιρετική /
Διαστάσεις Μ/Π/Υ 191x106x156 cm
Βάρος 302 kg
Änderungen und Irrtümer vorbehalten. Aus Angaben und Abbildungen können keine Ansprüche abgeleitet werden.

Accessories

product-image

Συσκευή αποτροπής εντόμων

Η συσκευή αποτροπής εντόμων της AS-Motor είναι ένα καινοτόμο εξάρτημα κοπής που προστατεύει τους επικονιαστές και την μικρή άγρια ζωή. Επιστημονικά δοκιμασμένη για να αυξήσει τα ποσοστά διαφυγής εντόμων, εξασφαλίζει βιώσιμο κούρεμα ενώ διατηρεί την αποδοτικότητα. Σχεδιασμένο για ανθεκτικότητα, προσαρμοστικότητα και εύκολη ολοκλήρωση με επαγγελματικά μηχανήματα κοπής της AS-Motor.

» read on
product-image

Τρέιλερ

Χώρος φορτίου: Μ = 1071 mm, Π = 607 mm, ύψος πάνελ: 274 mm. Επιτρεπόμενο συνολικό βάρος: 100 kg. Το πίσω πάνελ μπορεί να αφαιρεθεί.

product-image

Συζευκτής για Σέρπα (Sherpa)

Για τη σύνδεση του ρυμουλκουμένου AS.

product-image

Λεπίδα αποχιονισμού

Πλάτος: 1107 mm, ύψος: 348 mm. Ρυθμιζόμενο και στις δύο πλευρές.

product-image

Κιτ ανακύκλωσης χόρτου – AS Σέρπα

Για ακόμα πιο λεπτή κοπριά και πιο ομοιόμορφα αποτελέσματα κοπής σε γκαζόν με χόρτο μέχρι 40 cm ύψος.

product-image

Κλισιόμετρο

Βολική οθόνη κλίσης κλίσης.

product-image

Μοχλός στρίψιματος για το τιμόνι

Διευκολύνει το χείρισμα και την ευελιξία με το ένα χέρι σε επίπεδο έδαφος.

product-image

Υγρό σφραγιστικό ελαστικών “Plattfuss-Stop”

Μειώνει τους χρόνους βλάβης λόγω σκασμένων ελαστικών (950ml)
